Dual-function Brake Lathe Machine For Disc

Brand:
Shenyang 245
Product origin:
Shenyang, China
Delivery time:
To be negotiated
Supply capacity:
300 Units per Month
Dual-function Brake Lathe Machine For Disc

Dual-function Brake Lathe Machine for Disc belongs to the brake lathe machinery and is intended to resurface brake rotors on passenger cars, medium duty trucks. Dual-function means that Garage disc automatic brake machine supports car repairing both on and off vehicle operation, which would meet the different demands of people and makes the machine more flexible and save manpower. Dual–functions on one machine is definitely good tools for all customers.

Dual-function Brake Lathe Machine for Disc Introduction

Dual-function Brake Lathe Machine for Disc belongs to the brake lathe machinery and is intended to resurface brake rotors on passenger cars, medium duty trucks. Dual-function means that Garage disc automatic brake machine supports car repairing both on and off vehicle operation, which would meet the different demands of people and makes the machine more flexible and save manpower. Dual–functions on one machine is definitely good tools for all customers.

Brake Disc Machinery

Product Features

1. Besides working on the car, Dual-function Brake Lathe Machine for Disc can also work off-car.

2. Any brake disc that is unable to approach by on-car lathe, can be taken out and then lathe on Dual-function Brake Lathe Machine for Disc.

3. Only a few installation steps are new and Dual-function Brake Lathe Machine for Disc can be changed between on-car and off-car. That is more flexible and labor-efficient.

4. Dual-functions on one machine are definitely a money-marking tool for all customers.


Main Specifications

Working Height Min/Max

780/1200mm

Drive Speed

150RPM

Maximum Diameter Of Brake Disc

500mm

Motor/Power

220V/50Hz, 110V/60Hz, 750W

Thickness Of Brake Disc

6-40mm

Cutting Depth Per Knob

0.005-0.015mm

Cutting Precision

≤0.00-0.003mm

Brake Disc Surface

Roughness Ra

1.5-2.0μm

Gross Weight

128KG

Dimension

910 × 510 × 310mm

Product Details

1. A Set of Standard Adapters

Dual-function Disc Lathe Equipment


Disc Lathe1Screwdriver1
Clamp(112mm)1Hexagon Key(M6)1
Clamp(130mm)1Screw Nut1
Clamp(150mm)1Screw8
Taper Cone(46-78mm)1Nut Gasket2
Taper Cone(56-98mm)1Small Mounting Plate2
Taper Cone(75-123mm)1Universal Slide Mounting Without Thread1
Silencing Belt(8mm)1Universal Slide Mounting With Thread1
Silencing Belt (20mm)1Drive Adapter1
Silencing Belt (24mm)1The Drive Shaft Connecting Device1
Brush1Shims wash7
Spring1Spanner1
Lamp1Hook2





2. Twin Cutter

On-/Off-car Brake Disc Machine


3. Parameter

Brake Disc Machinery


4. Switches

Dual-function Disc Lathe Equipment


5. Outlet

On-/Off-car Brake Disc Machine
